Six Enamelling Techniques used for luxury watch making, from Patek Philippe to Cartier, Hermès and more

Enamelling may be a demanding art, but its organic creation process and numerous techniques available makes for endless possibilities and much to admire

Apr 16, 2017 | By LUXUO
Enamelling at Swiss watchmaker A. Lange & Söhne

Enamelling at Swiss watchmaker A. Lange & Söhne

Enamelling is a tedious process, to put it mildly. The raw material must first be ground into a fine powder, then mixed with a suitable medium (oils or water are both used) to form a paint-like emulsion. This liquid is then applied like paint, before being fired in a kiln to vitrify it the medium evaporates, while the powder melts and fuses into glass. There are variations to these steps, of course. Some manufactures, for example, choose to sieve the power directly onto a base of either brass or gold, and fire this “layer” of powder directly. Whatever the process, every step is fraught with danger. The product may crack during the firing process. Unseen impurities may surface as imperfections. Colours may react in unexpected ways. There are numerous risks to endure. Why, then, does this technique continue to be used in watchmaking?

Despite all its drawbacks, enamel still has a depth and nuance that cannot be replicated anywhere else. It is also permanent vitrified enamel is essentially inert and, like noble metals, remains unchanged even a century from now. Different enamelling techniques are capable of creating a wide spectrum of products as well, from a single large surface free of blemishes, to microscopic levels of detail as part of a painting. Perhaps the romantic aspect of this metiers d’art also accounts for part of its appeal; the time and touch of the enamellist is the perfect counterpoint to the watchmaker, with art on one side and science on the other.

Variations on a Theme

Enamels are fired at various temperatures or not at all depending on their types. Grand feu (literally “great fire”) enamel is fired at around 820 degrees Celsius, although intermediate firings to “set” it may be at around 100 degrees Celsius, to boil the solvent off without fusing the powder. Enamels in general, including those used in miniature painting, may also be fired at around 100 degrees Celsius instead. Finally, there is cold enamel, an epoxy resin that cures and hardens at room temperature.

There are no hard and fast rules to the craft; every enamellist has his/her own materials and approach

There are no hard and fast rules to the craft; every enamellist has his/her own materials and approach

What difference does it make? For a start, higher temperatures are definitely more difficult to work with, since the enamel may crack during firing, or the subsequent cooling down process. The spectrum of colours used in grand feu enamelling is also more limited, as there are fewer compounds that can withstand the temperature. The choice of technique boils down to the desired product for all its drawbacks, grand feu enamel has an inimitable look.

Seiko’s Presage SRQ019 chronograph with white enamel dial

Seiko’s Presage SRQ019 chronograph with white enamel dial

Enamels, porcelains, and lacquers all share common properties of hardness, durability, and the ability to take on both matte and polished finishes. The three aren’t interchangeable though. Lacquer is an organic finish that is applied in layers, with each successive coat curing at room temperature before the next is added. Porcelain is a ceramic that is produced by firing materials in a kiln to vitrify them. Although enamel is also fired, it only contains glass and colouring compounds and lacks porcelain’s clay content.

Raised Fields

In champlevé enamelling, a thick dial base is engraved to create hollow cells, before these cavities are filled with enamel and fired. Because the engraving step produces rough surfaces at the bottom of each cell, the champlevé technique typically uses only opaque enamels. The method allows areas on the dial to be selectively excavated, and for enamels to be mixed freely within each dial. This is done to great effect in Piaget’s Emperador Coussin XL Large Moon Enamel watch, where the gold dial is largely untouched for the “continents”, while the “oceans” are created in champlevé enamel, with differing shades of blue to convey their varying depths.

An excavated cell in Ulysse Nardin’s Classico Goat being filled with enamel using the champlevé technique

An excavated cell in Ulysse Nardin’s Classico Goat being filled with enamel using the champlevé technique

Champlevé enamelling’s use isn’t limited to creating decorative art. In Parmigiani Fleurier’s Tecnica Ombre Blanche, for instance, it was simply the most appropriate technique. Although the timepiece has a simple white enamel dial, its surface is interrupted by three sub-dials and an aperture for the tourbillon. Using champlevé enamelling here allowed each dial element to have a clearly defined border without adding unnecessary thickness. A possible alternative would be to make a complete enamel dial, before cutting out the appropriate sections in the middle. One can, however, imagine the risks of doing that.

Patek Philippe’s Ref. 6002 combines champlevé and cloisonné enamelling

Patek Philippe’s Ref. 6002 combines champlevé and cloisonné enamelling

Is there a limit to the level of details that can be achieved with champlevé enamel? Patek Philippe may have the answer with the Ref. 6002 Sky Moon Tourbillon. Apart from the centre portion, which is produced using the cloisonné technique (discussed later), its dial is a work of champlevé enamel even the railway track chapter ring was milled out in relief, before the recesses are filled with enamel and fired.

Engraving isn’t necessarily the only way to produce the cells used in champlevé enamel though. Hublot puts a modern twist on things with the Classic Fusion Enamel Britto, by stamping the white gold dial base to create the raised borders between the cells. This not only reduces the time needed for each dial but also ensures uniformity between them. Subsequent steps, however, remain unchanged the cells were sequentially filled with different colours of enamel and fired multiple times before the entire dial surface is polished to form a uniformly smooth surface.

Wire Work

Cloisonné enamelling is almost like the opposite of the champlevé technique instead of removing material from a dial blank, things are added on it instead. The “cloisons” (literally “partitions”) here refer to the wires, each no thicker than a human hair, that the enamellist bends into shape and attaches onto a base to create enclosed cells. These cells are then filled with enamel of different colours before the dial is fired to fuse the powder. The wires remain visible in the final product, and look like outlines of a drawing, with a metallic sheen that contrasts with the glassy surfaces of the enamel.

Wires are shaped and attached to a dial to form cells, before enamel is painted in

Wires are shaped and attached to a dial to form cells, before enamel is painted in

Plique-à-jour (“letting in daylight”) enamel can be considered a variation of cloisonné enamel, but the technique is a lot rarer owing to its complexity and fragility. Like its cloisonné sibling, plique-à-jour enamelling involves creating enclosed cells using wires, before filling them with enamel. In this case, however, there is no base. The lack of a backing can be achieved in various ways, but usually involves working on a base layer à la cloisonné enamelling, before filing it away to leave just the wires holding onto vitrified enamel. Since there is no base, plique-à-jour enamelling almost always involves transparent or translucent enamel that allows light through, which essentially creates tiny stained glass windows.

A dial in cloisonné enamel is in the making

A dial in cloisonné enamel is in the making

Van Cleef & Arpels has used the above technique to great effect. In the Lady Arpels Jour Nuit Fée Ondine watch, a 24-hour module rotates a graduated lower dial once a day to mimic Earth’s diurnal rhythm, while an upper dial with elements executed in plique-à-jour enamel forms the foreground. The watch thus creates an ever-changing scene that mimics the rising and setting of the sun and moon, with the appropriate shades of blue for the sky and water, depending on the time of the day.

Hybrid Theory

There are several “hybrid” techniques that combine enamelling with other decorative arts, and flinqué enamelling is arguably the best known given its long history of use. The technique combines guillochage with enamelling a brass or gold dial is first decorated with guilloché, before layers of enamel are successively applied and fired. When this enamel coating is sufficiently thick, it is polished to create a smooth surface; the final result is a translucent lens through which the guilloché is admired. Depending on the desired effect, the enamel used may be colourless to impart a subtle sheen, or coloured for more visual oomph, like the trio of limited edition Rotonde de Cartier high complications unveiled at Watches & Wonders 2015. Vacheron Constantin has even adapted the technique by using guilloché patterns to mimic woven fabrics in the Métiers d’Art Elégance Sartoriale.

Enamel being applied to the engraved white gold base on the Hermès Arceau Tigre

Enamel being applied to the engraved white gold base on the Hermès Arceau Tigre

Developed by the husband-and-wife team of Olivier and Dominique Vaucher, shaded enamel (email ombrant) also involves the application of translucent enamel over an engraved dial. Instead of a regular pattern à la guilloché, however, shaded enamel entails the creation of an image in relief. In the Hermès Arceau Tigre, the likeness of the animal is first carved into a white gold base, before translucent black enamel is applied and fired. A thicker layer of enamel accumulates in areas where the engraving is deeper and appears darker as a result the shading corresponds to the depth of the enamel, which creates an extremely lifelike product.

Cartier Ballon Bleu de Cartier Enamel Granulation with Panther Motif

Cartier Ballon Bleu de Cartier Enamel Granulation with Panther Motif

The final technique here is Cartier’s enamel granulation, which combines enamelling with Etruscan granulation originally used by goldsmiths. The craft requires multiple steps and is extremely tedious, to say the least. Enamel is first worked into threads of different diameters before these threads are chipped off bit by bit to form beads of various sizes. The beads are then sorted by colour and applied to the dial successively to assemble an image, with intermediate firings to set and fuse the enamel. As different colours of enamel fuse at different temperatures, there is a clearly defined order for the assembly process; up to 30 firings are necessary, and each dial requires nearly a month to complete. Like shaded enamel, enamel granulation is a very recent development, and Cartier has only used it on one watch so far: the Ballon Bleu de Cartier Enamel Granulation with Panther Motif.

Metallic Content

Paillonné is among the rarest enamelling techniques today and practically synonymous with Jaquet Droz, which has maintained its expertise in this area. The manufacture currently has two full-time enamellists who don’t just produce enamel dials but also train artisans to perpetuate this know-how.

A paillon being applied to the coloured enamel “base”

A paillon being applied to the coloured enamel “base”

The “paillon” here refers to the small ornamental motifs that are created from gold leaf, and are the calling card of the technique. Essentially, paillonné enamelling involves setting paillons within enamel to form patterns, with regular geometric ones being the norm. To do so, a layer of coloured enamel is first fired to set it. Upon this layer, the paillons are positioned, before translucent enamel is applied and fired, thus “locking” the paillons in. Additional steps can be taken to create even more intricate designs. Before the coloured enamel layer is applied, for instance, the substrate surface may first be decorated with guilloché, which basically creates flinqué enamel that is then decorated with paillons over it. According to Jaquet Droz’s CEO Christian Lattmann, the textured base doesn’t just offer visual benefits but also helps the initial layer of coloured enamel to “stick” better. Lattmann also revealed that the choice of white or red gold as this base will impart a different tone to the finished product as well both because of its inherent colour and because of how the guillochage plays with light.

A watch from Vacheron Constantin’s Métiers d’Art Villes Lumières collection, with applied precious metal powders on the enamelled surface

A watch from Vacheron Constantin’s Métiers d’Art Villes Lumières collection, with applied precious metal powders on the enamelled surface

In lieu of regular patterns, Jaeger-LeCoultre opted for a twist on the technique, by distributing flecks of silver randomly on the dial instead. The result can be seen in the Hybris Artistica Duomètre Sphérotourbillon Enamel, whose enamel dial mimics the look of lapis lazuli. This technique was also used for the second dial of the Reverso One Duetto Moon.

Jaeger-LeCoultre Reverso One Duetto Moon

Jaeger-LeCoultre Reverso One Duetto Moon

While not paillonné enamelling per se, Vacheron Constantin’s use of hand applied precious powder deserves a mention here. In the manufacture’s Métiers d’Art Villes Lumières timepieces, gold, platinum, diamond, and pearl powders are affixed to the surface of the enamel dial by Japanese enamel artisan Yoko Imai. Instead of being covered with a layer of enamel, these particles sit atop them, and catch the light variously to mimic a bird’s eye view of a city at night.

Brush Strokes

Enamel painting is simply painting with enamel pigments rather than some other medium. The technique is challenging not just due to the canvas’s size, which makes it miniature painting as well, but also because of the multiple firings needed to vitrify and set the enamels, colour by colour. Given the level of detail that can be achieved, however, this is one of the few techniques that are capable of making their subjects almost lifelike. Consider Slim d’Hermès Pocket Panthère, which has the eponymous animal rendered in this technique, for example. Jaeger-LeCoultre’s Reverso à Eclipse also showcases what enamel painting is capable of with its uncanny facsimile of Van Gogh’s Self-Portrait as a Painter on its dial.

Slim d’Hermès Pocket Panthère being painted. Image © Pierre-William Henry

Slim d’Hermès Pocket Panthère being painted. Image © Pierre-William Henry

Grisaille enamel can be considered a subset of enamel painting, and is a specific method of painting white on black to create monochromic imagery. The black canvas is grand feu enamel that must first be applied, fired, and then polished to create a perfectly smooth surface that’s free of imperfections. This preparatory step is, in and of itself, already very challenging, as minute flaws are extremely easy to spot on such a surface this explains why most watch brands offer white enamel dials, but black onyx or lacquer dials instead of enamel. Upon this black canvas, the enamellist paints using Blanc de Limoges, which is a white enamel whose powder is more finely ground than normal. To create micro details, fine brushes, needles, and even cactus thorns are used, and the dial is painted and fired multiple times to create the nuanced paintings grisaille enamel is known for.

Grisaille enamel painting for Van Cleef & Arpels’s Midnight Nuit Boréale

Grisaille enamel painting for Van Cleef & Arpels’s Midnight Nuit Boréale

Owing to its complexity, grisaille enamel is rarely seen. There are brands that still offer metiers d’art watches with them though, sometimes with their own take on the technique. In its Métiers d’Art Hommage à l’Art de la Danse collection, Vacheron Constantin opted to use translucent brown enamel for the dial base to impart a greater sense of depth, while softening the contrast between the two colours. Van Cleef & Arpels used a midnight blue base in its Midnight Nuit Boréale and Nuit Australe timepieces instead, to evoke the night sky.

This article was originally published in WOW.
